Technical Stuff



Main Stage:

Capacity – 250

Custom 4way active, 5kw PA system comprising:

2x 3way full range enclosure, 2×15” Bass, 1×12” + 2x 8” Mid, 1x 1” compression driver HF

4x Cerwin Vega 1×18” Sub Bass enclosure

1 full range and 2 Sub enclosures per side

Amp room FOH drive

2x XTA 226 processors (House techs and visiting engineers do not have access to system controllers)

Crest Audio CA6 HF 8 ohms

Crest Audio CA6 Mids 8 ohms

Crown Micro Tech 1200 Mid 310w per channel 8ohms, 560w per channel 4ohms, operating @ 5 ohms

Crown Macrotech ma3600vz Bass, 965w per channel 8ohms, 1325w per channel 4ohms, operating @ 4 ohms, (Beyma 15P1200ND)

Crown Macrotech ma3600vz Sub, power ratings as above, operating at 4 ohms, Drivers are a mix of Fane and Celestian 18”

FOH Control

Midas M32 digital console with DL32 remote stagebox

USB 32 channel digital interface for Mac or PC

TP-Link router for Mac, PC, Andriod, IOS control

Amp room Monitors 6 sends

2x Alto 2.4 power amps, 560w per channel 8 ohms, 900w per channel 4 ohms

1x Yamaha PM4500 460w per channel 8 ohms, 620w per channel 4 ohms

Monitors

3x Martin Le400 type passive wedges 15” + 1”

2 x Cerwin Vega SM15B

Drum Fill 2×15” +1”

Microphones and DI’s

AKG D112

3 x Shure SM57

6 x Shure SM58

6 x Sennheiser e604

1 x Sennheiser 835

1 x JTS NX-9

1 x JTS NX-7

2 x IMG Stageline Stereo passive DI

1 x IMG Stageline Mono Passive DI
